Specifications
| Image Sensor | CMOS |
|---|---|
| Light Source | White LED |
| Optical Resolution | 5 Megapixels |
| Focus | Fixed |
| Scan Modes | Color: 24-bit Input; 24-bit Output |
| Scanning Speed | Approx. 1 sec (Color Mode, Full Page passport image capture) |
| Scanning Area (W x L) | Maximum: 127 x 95 mm | [us] Maximum: 5″ x 3.74″ |
| Acceptable Paper Sizes (W x L) | Maximum: 125 x 88 mm (4.92″ x 3.46″) |
| Action Button | Dual Auto Detect Sensors |
| Power Supply | USB Power: 5V / 0.5A |
| Interface | USB 2.0 Type B |
| Net Weight | 1.7 kg | [us] 3.78 lbs |
| Dimensions (W x D x H) | Without Cover: 200 x 200 x 119 mm With Cover: 200 x 200 x 190 mm | [us] Without Cover: 7.87″ x 7.87″ x 4.69″ With Cover: 7.87″ x 7.87″ x 7.48″ |
| Operating System | Windows 7 / 8 / 8.1 / 10 / 11
Linux compatibility is only available for system integrators. Please contact sales@plustek.com for more info.(SDK only) |
| Hardware Requirements | 2.0 GHz CPU processor or higher[1] [1]Windows Recommended: 2.8 GHz Intel® Core™ i5 Processor with 4 CPU Cores or higher 4 GB RAM minimum (Recommended: 8 GB or more) 6 GB of hard-disk space for program installation USB2.0 or above Display dimensions of 1024×768 or greater |
| Bundled Software | Plustek SecureScan Plustek SecureScan Manager |
